Case Excavator 9040b, Schematic Set Pdf Manual



Case Excavator 9040b, Schematic Manual
Contents :
Safety, General Information and Standar Torque Specs
6-830 Diesel Specs DEtails
Electrical Specs and Troubleshooting
Electrical Schematic
Tracks, Rollers and Idlers
Hydraulic Specs, Trobleshooting and Pressure Checks
Hydraulic Schematic

Case 9040B Excavator Operators Pdf Manual Download


Make Case
Model 6T-830
Net Power 178 hp 132.7 kw
Power Measured @ 2200 rpm
Displacement 505 cu in 8.3 L
Torque Measured @ 1500 rpm
Max Torque 574 lb ft 778.2 Nm
Number of Cylinders 6
Aspiration Turbocharged
Operating Weight 53140 lb 24103.9 kg
Fuel Capacity 81.9 gal 310 L
Cooling System Fluid Capacity 6.7 gal 25.5 L
Hydrauilc System Fluid Capacity 58.1 gal 220 L
Engine Oil Capacity 5.8 gal 22 L
Swing Drive Fluid Capacity 1.6 gal 6 L
Operating Voltage 24 V
Alternator Supplied Amperage 65 amps
Hydraulic System Relief Valve Pressure 4554 psi 218 kPa
Hydraulic Pump Flow Capacity 56 gal/min 212 L/min
Swing Mechanism
Swing Speed 10.4 rpm
Number of Shoes per Side 51
Shoe Size 32 in 812.8 mm
Number of Carrier Rollers per Side 2
Number of Track Rollers per Side 9
Ground Pressure 5.2 psi 35.9 kPa
Max Travel Speed 3.4 mph 5.5 km/h
Drawbar Pull 43000 lb 191.3 kN

Case Excavator 9040b, Schematic Set Pdf Manual

Reference Bucket Capacity 1.2 yd3 0.92 m3
Minimum Bucket Capacity 0.95 yd3 0.73 m3
Maximum Bucket Capacity 1.8 yd3 1.4 m3
Boom/Stick Option (HEX) 1
Boom/Stick Option (HEX) 1 Boom 19’2″ (5800mm)/ Stick 11’7″ (3500mm)
Shipping Height of Unit 10.6 ft in 3220 mm
Shipping Length of Unit 32.8 ft in 10010 mm
Max Digging Depth 24.2 ft in 7390 mm
Max Reach Along Ground 35 ft in 10670 mm
Max Cutting Height 32.6 ft in 9930 mm
Max Loading Height 22.6 ft in 6880 mm
Max Vertical Wall Digging Depth 21.9 ft in 6680 mm
