Hitachi ZX170W-5A and ZX170W-5B Excavator Service Repair Manual

For Model: Excavator ZX170W-5A and ZX170W-5B
Format: PDF
Language: English
Service Manual consists of the following:

For Model ZX170W-5A:

Service Manual (Troubleshooting) : Vol. No.TOLBJEO
Service Manual (Operation) : Vol. No.TTLBJEO
Workshop Manual : Vol. No.WLBJEO

For Model ZX170W-5B:

Service Manual (Troubleshooting) : Vol. No.TOLBA-EN
Service Manual (Operation) : Vol. No.TTLBA-EN
Workshop Manual : Vol. No.WLBA-EN

SI Units (International System of Units) are used in those manual.
Circuit Diagram

Manual guide composition

Hitachi ZX170W-5A and ZX170W-5B service manual consists of the Operating, Troubleshooting and the Workshop Manual.

• Information included in the Service Manual: Technical information needed for redelivery and delivery, operation and activation of all devices and systems, operational performance tests, and troubleshooting procedures.
• Information included in the Workshop Manual: Technical information needed for maintenance and repair of the machine, tools and devices needed for maintenance and repair, maintenance standards, and removal / installation and assemble / disassemble procedures.

To avoid injury and damage refer to the service manual and be sure to use appropriate lifting techniques and equipment when lifting heavy parts.

The Cab assembly weight:
370 kg (820 lb)

The Hitachi excavators ZX170W-5A and ZX170W-5B has been built to deliver reliable performance with fewer emissions and less fuel. Less fuel consumption for owners, easier for operators and better for the environment, the ZX170W-5A and ZX170W-5B incorporates the latest technologies made for the hydraulic, electric and capacitor-powered excavators.

We will only send you either the 5A variant manual or the 5B. Please specify which model when ordering.

Hitachi ZX170W-5A and ZX170W-5B Excavator Service Repair Manual
