Hitachi ZX470-6, ZX490LCH-6 and ZX530LCH-6 Excavator Repair Manual

Hitachi ZX470-6, ZX490LCH-6 and ZX530LCH-6 Excavator Repair Manual

Hitachi Excavator

Manual is applicable for:
ZX470-6
ZX470LC-6
ZX490H-6
ZX490LCH-6
ZX490R-6
ZX490LCR-6
ZX530LCH-6
Language: English
Format: PDF

Service Manual consists of the following separate Part No;
Technical Manual (Operational Principle) : Vol. No.TOJAG50-EN
Technical Manual (Troubleshooting) : Vol. No.TTJAG50-EN
Workshop Manual : Vol. No.WJAG50-EN

Electrical Circuit Diagram

This manual is written for an experienced technician to provide technical information needed to maintain and repair this machine. The machine specification and description according to destination may be explained on this manual.

Hitachi ZX650LC-3 and ZX670LCH-3 Manual Composition

This manual consists the Technical Manual, the Workshop Manual and the Service Manual.

• Information included in the Technical Manual:
  Technical information needed for redelivery and delivery, operation and activation of all devices and systems, operational performance tests, and troubleshooting procedures.
• Information included in the Service Manual:
  Technical information needed for maintenance and repair of the machine, tools and devices needed for maintenance and repair, maintenance standards, and removal / installation and assemble / disassemble procedures.

Repair any defects and damage found, such as oil or water leaks, loose bolts, cracks and so on, before starting to test.

Hitachi ZX470-6, ZX490LCH-6 and ZX530LCH-6 Excavator Repair Manual
