Hitachi AH250 Articulated Dump Trucks (SN 409812.00 – 410812.00) Parts Catalog Manual
The part numbers in this Parts Catalog (87204301B) were correct at the time of publication. Therefore, when ordering parts verify the part numbers with your dealer.
John Deere Model: AH250
Type: Parts Catalog
Serial Number: 409812.00 – 410812.00
Language: English
Format: PDF
Publication: 87204301B
- Hitachi AH250 Articulated Dump Trucks (SN 409812.00 – 410812.00) Parts Catalog – 399 Pages
The part numbers in this Parts Catalog (87204301B) were correct at the time of publication. Therefore, when ordering parts verify the part numbers with your dealer.
SI Units of Measure
Metric dimensions are provided as applicable throughout this parts catalog.
Hitachi AH250 Articulated Dump Trucks (SN 409812.00 – 410812.00) Parts Catalog Manual
Bolt and Cap Screw Strength Identification
Bolts and cap screws required to have high-strength qualities equivalent to metric property class 10.9 (SAE grade 8) or higher are identified throughout this catalog by the description 10.9, 12.9 or 14.9. All standard bolts and cap screws are metric property class 8.8 (SAE grade 5) or lower.
The Hitachi AH250 Articulated Dump Trucks Parts Catalog Manual (SN 409812.00 – 410812.00) is a vital tool for precise parts lookup and efficient maintenance. Featuring clear diagrams and accurate OEM part numbers, this manual helps reduce downtime, prevent ordering errors, and keep your fleet operating at maximum productivity. An indispensable reference for owners and service professionals seeking long-term reliability and performance.
