Bobcat S220 Service Repair Manual
Description
Bobcat S220 This service manual includes technical service information, installation instructions, pictures, and other service information for BOBCAT S220 SKID STEER LOADER SN A5GL11001 – A5GL19999.
Bobcat S220 Service Repair ManualService manual contains detailed diagrams and charts that help you to get a detailed description of all the systems of skid steer loaders Bobcat.
This Bobcat manual comes in PDF format. Working with this manual, you can easily copy, save, and print the information you need. We recommend to use Adobe PDF Reader, to be sure all images/graphics will display correctly.
CAPACITIES: Bobcat S220 Service Repair Manual
Fuel Tank ……. 23 gals. (87,1 L)
Engine Oil with Filter…..14 qts. (13,3 L)
Engine Coolant …4.3 gals. (16,3 L)
Hydraulic/Hydrostatic Reservoir…4.7 gals. (17,8 L)
Hydraulic/Hydrostatic System .. 13 gals. (49,2 L)
Transmission (Final Drive)…11 gals. (41,6 L)
Main Drive….. Fully hydrostatic, 4-wheel drive
Transmission … Infinitely variable tandem hydrostatic piston pumps,
driving two fully reversing hydrostatic motors
Final Drive Chains … Pre-stressed #120 HSOC endless roller chain (no master link)
and sprockets in sealed chaincase with oil lubrication
(Chains do not require periodic adjustments)
Two chains per side with no idler sprocket
Axle Size…. 2.76 in. (70,1 mm), heat treated
Wheel Bolts …. (8) 9/16 in. wheel bolts fixed to axle hubs.
CONTROLS
Vehicle Steering. Direction and speed controlled by two hand levers
Loader Hydraulics
Lift & Tilt …. Controlled by separate foot pedals or optional Advanced Control System (ACS)
or optional Selectable Joystick Controls (SJC)
Front Auxiliary (Std.) ……. Controlled by an electrical switch on the Right-Hand steering lever
Rear Auxiliary (Opt.) ……. Controlled by an electrical switch on the Left-Hand steering lever
Auxiliary Pressure Release … Pressure is relieved through the coupler block, push in and hold for five seconds
Engine …….. Hand lever throttle; key-type starter switch and shutdown
Starting Aid ……… Air Intake Heater – automatically activated by standard or Deluxe, Instrument Panel Service Brake…… Two independent hydrostatic systems controlled by two hand-operated steering levers.
Instructions are necessary before operating or servicing machine. Read andunderstand the Operation & Maintenance Manual, Operator’s Handbook andsigns (decals) on machine. Follow warnings and instructions in the manualswhen making repairs, adjustments or servicing. Check for correct function afteradjustments, repairs or service. Untrained operators and failure to followinstructions can cause injury or death.
