CASE 9020 Excavator Operators Pdf Manual DOWNLOAD
$59.99
⚙️ Get the official CASE 9020 Excavator Operators Pdf Manual DOWNLOAD. Professional-grade technical data for instant repair.
- 📂 Format: High-resolution PDF — Interactive index included.
- 🔧 Coverage: Full engine overhauls, wiring diagrams, and hydraulics.
- ⚡ Delivery: Immediate digital access right after checkout.
💻 Read directly on your phone, tablet, or laptop.
CASE 9020 Excavator Operators Pdf Manual DOWNLOAD
Manual Covers: 9020 excavator for sale, case 9020 sale, used case 9020, case 9020 hydraulic excavator
- Product Specifications
- Brand: Case CE (Construction Equipment)
- Model: 9020 Crawler Excavator
- Publication Number: Bur 9-23810 (or equivalent factory operator series)
- Language: English
- Format: Digital PDF Document
- Compatibility: Fully compatible with all operating systems (Windows, Mac, iOS, Android)
Lubrication/Maintenance Charts
Lubrication/Fiters/Fluids
Maintenance And Lubrication
Electrical System
Specifications
Machine Storage
Index
After Delivery Check
And More……
File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader & WinZip
CASE 9020 Excavator Operators Pdf Manual DOWNLOAD
Specification
Engine
Make Case
Model 4TA-390
Net Power 106 hp 79 kw
Power Measured @ 2200 rpm
Displacement 239 cu in 3.9 L
Torque Measured @ 1450 rpm
Max Torque 325 lb ft 440.6 Nm
Aspiration turbocharged and aftercooled
Number of Cylinders 4
Operational
Operating Weight 35274 lb 16000 kg
Fuel Capacity 63 gal 238.5 L
Cooling System Fluid Capacity 4.1 gal 15.7 L
Hydrauilc System Fluid Capacity 37.5 gal 142 L
Engine Oil Capacity 2.7 gal 10.2 L
Swing Drive Fluid Capacity 1.3 gal 5 L
Operating Voltage 24 V
Alternator Supplied Amperage 45 amps
Hydraulic System Relief Valve Pressure 4550 psi 217.9 kPa
Hydraulic Pump Flow Capacity 36.5 gal/min 138 L/min
Swing Mechanism
Swing Speed 11.3 rpm
Undercarriage
Number of Shoes per Side 43
Shoe Size 23.6 in 599.4 mm
Number of Carrier Rollers per Side 2
Number of Track Rollers per Side 7
Ground Pressure 5.5 psi 37.9 kPa
Max Travel Speed 3.4 mph 5.5 km/h
Drawbar Pull 28880 lb 128.5 kN
Buckets
Reference Bucket Capacity 0.61 yd3 0.47 m3
Minimum Bucket Capacity 0.5 yd3 0.38 m3
Maximum Bucket Capacity 1.1 yd3 0.86 m3
Boom/Stick Option (HEX) 1
Boom/Stick Option (HEX) 1 Boom 16’11” (5150mm)/ Stick 8’10” (2700mm)
Shipping Height of Unit 9.5 ft in 2910 mm
Shipping Length of Unit 27.3 ft in 8310 mm
Max Digging Depth 20 ft in 6110 mm
Max Reach Along Ground 29.3 ft in 8920 mm
Max Cutting Height 30.1 ft in 9180 mm
Max Loading Height 21.5 ft in 6550 mm
Max Vertical Wall Digging Depth 17.3 ft in 5260 mm
Boom/Stick Option (HEX) 2
Boom/Stick Option (HEX) 2 Boom 16’11” (5150mm)/ Stick 10’0″ (3050mm)
Shipping Height of Unit 10.2 ft in 3100 mm
Shipping Length of Unit 27.6 ft in 8400 mm
Max Digging Depth 21.2 ft in 6460 mm
Max Reach Along Ground 30.6 ft in 9320 mm
Max Cutting Height 31.4 ft in 9580 mm
Max Loading Height 22.7 ft in 6920 mm
