Doosan P158LE, P180LE, P222LE, PU158TI  Maintenance Manual

PU180TI / PU222TI

Operation & Maintenance Manual

GENERATOR DIESEL ENGINE

P158LE / -1 / – 2 / -S / -III

P180LE / -1 / -S / -II

P222LE / -1 / -S / -II

POWER UNIT DIESEL ENGINE

PU158TI

PU180TI

PU222TI

This manual is designed to serve as an instruction for Diesel generator engine and Power Unit engine of

DOOSAN series (P158LE /P180LE /P222LE, PU158TI/ PU180TI/ PU222TI).

The engines are 4 strokes, 2 valves per cylinder, V-type, and direct injection mode and thus, are also satisfying with various features required as generator and power unit engine such as quiet operation, economical fuel consumption, durability in high-speed operation, and so forth.

We are very confident that these engine series are quite superior to any high-speed engines in economy and efficiency. However, high performance and long life cycle will be accomplished when proper handling and administration of periodic inspections and maintenance should be observed. Readers are desired to know for your reference that those kinds of maintenance matters are explained here in detail by means of figures and diagrams.

Doosan P222LE PU158TI Engine Maintenance Manual

Models Covered:

Doosan P158LE / P180LE / P222LE, PU158TI / PU180TI / PU222TI Diesel Engine Operation & Maintenance Manual

Manual Covers:

1. Safety Regulations & Engine Specifications

2. Technical Information

3. Disassembly and Reassembly of Major Components

4. Commissioning and Operation

5. Maintenance of Major Components

6. Special Tool List

And More…

In this manual, the following symbols are used to indicate the type of service operations to be performed.

Removal Adjustment

Installation Cleaning

Disassembly Pay close attention-Important

Reassembly Tighten to the specified torque

Align the marks Use special tools of manufacturer’s

Directional Indication Lubricate with oil

Inspection Lubricate with grease

Measurement.
