Hitachi ZX160LC-5G and ZX160LC-6 Excavator Service Repair Manual

For Model: Excavator ZX160LC-5G and ZX160LC-6
Format: PDF
Language: English
Service Manual consists of the following:

For Model ZX160LC-5G:
Service Manual (Troubleshooting) : Vol. No.TODBG-EN
Workshop Manual : Vol. No.WDBG-EN

Electrical Circuit Diagram

For Model ZX140-6:
Service Manual (Troubleshooting) : Vol. No.TODBR50-EN
Workshop Manual : Vol. No.WDBR50-E-EN

Electrical Circuit Diagram

SI Units (International System of Units) are used in those manual.

Manual guide composition

Hitachi ZX160LC-5G and ZX160LC-6 service manual consists of the Operating, Troubleshooting and the Workshop Manual.

• Information included in the Service Manual: Technical information needed for redelivery and delivery, operation and activation of all devices and systems, operational performance tests, and troubleshooting procedures.
• Information included in the Workshop Manual: Technical information needed for maintenance and repair of the machine, tools and devices needed for maintenance and repair, maintenance standards, and removal / installation and assemble / disassemble procedures.

To avoid injury and damage refer to the service manual and be sure to use appropriate lifting techniques and equipment when lifting heavy parts.

The Cab assembly weight:
550 kg (1220 lb)

The Hitachi excavators ZX160LC-5G and ZX160LC-6 has been built to deliver reliable performance with fewer emissions and less fuel. Less fuel consumption for owners, easier for operators and better for the environment, the ZX160LC-5G and ZX160LC-6 incorporates the latest technologies made for the hydraulic, electric and capacitor-powered excavators.

We will only send you either the -5G variant manual or the -6. Please specify which model when ordering.

Hitachi ZX160LC-5G and ZX160LC-6 Excavator Service Repair Manual
