Hitachi ZX500LC and ZX500LCH Excavator Service Repair Manual
$49.00
Hitachi ZX500LC and ZX500LCH Excavator Service Repair Manual
The manual is applicable for the ZX500 Hitachi Excavator Model
Format: PDF
Language: English
Service Repair Manual consists of the following:
See description for full details
Hitachi ZX500LC and ZX500LCH Excavator Service Repair Manual
The manual is applicable for the ZX500LC and ZX500LCH Hitachi Excavator Model
Format: PDF
Language: English
Service Manual consists of the following:
For Model ZAXIS ZX500LC and ZX500LCH as mentioned above:
Service Manual (Troubleshooting) : Vol. No.TO16RE
Service Manual (Operation) : Vol. No.TT16RE
Workshop Manual : Vol. No.W16RE
Parts Catalog
SI Units (International System of Units) are used in those manual.
Manual guide composition
Hitachi ZX500LC and ZX500LCH service manual consists of the Operating, Troubleshooting and the Workshop Manual.
- Information included in the Service Manual: Technical information needed for redelivery and delivery, operation and activation of all devices and systems, operational performance tests, and troubleshooting procedures.
- Information included in the Workshop Manual: Technical information needed for maintenance and repair of the machine, tools and devices needed for maintenance and repair, maintenance standards, and removal / installation and assemble / disassemble procedures.
To avoid injury and damage refer to the service manual and be sure to use appropriate lifting techniques and equipment when lifting heavy parts.
A ZAXIS hallmark industry-leading hydraulic technologies, and performance no other can beat. New ZAXIS provides reliable solutions: impressive fuel economy, swift front movements, and easy operation. You’ll also find Hitachi technological prowess and expertise, such as the optimized hydraulic system and engine.New ZAXIS features the key benefits of high quality, low fuel consumption, and high durability, all of which serve to ensure low running costs.New ZAXIS, which is empowered by comprehensive evolution, will realize customers visions and dreams, and pioneer your colorful future
Troubleshooting B Extract:
In the HP mode, engine speed is not increased during arm roll-in or boom raise.
Related Fault Code: 10, 11, 15 and 16
• Sensors detect the conditions necessary to operate the HP mode. Therefore, if any of these sensor fails, the HP mode becomes inoperable.
• Pressure sensors (arm roll-in and boom raise) and pump 1 and 2 delivery pressure sensors are also engaged in the HP mode control. However, if these sensors fail, other operating functions will be also affected. (Refer to the relationship between machine trouble symptoms and related parts on page T5-4-2.)
