Timberjack 608L Feller Buncher Service Repair Manual

This variation, however, does not have any impact on the accuracy of the written information. The information contained in this manual is current at the time of publication; however, continuing product improvement may result in changes to the machine which are not covered.

Model: Timberjack 608L Feller Buncher ( S/N: 10BA1017 and up)

Type: Feller Buncher

Language: English

Format: PDF

Timberjack 608L Feller Buncher Repair Service Manual – 468 Pages

Timberjack 608L Manual Table of Content

Section 0000 – General

0010 – How to Use This Book

0020 – Section and Group Contents 0030- Foreword and Warranty

0040 – Safety

0050 – Alphabetical Index

0060 – Major Component Locations

Section 1000 – Power Unit

1100 – Engine

1110 – Engine Enclosure Door

1200 – Engine Mounted Equipment

1310 – Engine Mounting

1320 – Removal/Installation

1400 – Fuel System – General

1410 – Fuel System

1500 – Cooling System – General

1510 – Cooling System

1511 – Radiator

1700 – Air Intake System – General

1800 – Exhaust System – General

1900 – Miscellaneous – (Horsepower Test)

Section 2000 – Hydraulic System

2000 – Hydraulic Circuits

2110 – Main Pump

2120 – Auxiliary Pump

2130 – Pilot Pump

2210 – Drive Motor

2220 – Swing Motor

2410 – Main Control Valves

2420 – Auxiliary Valves

2430 – Pilot Valves

2600 – Brake Hydraulics – General

2700 – HydrauHc Tanks – General

2800 – Cylinders – General

2810 – Cylinders

2910 – Swing/Rotary Manifold

2950 – Hydraulic Cooling

Section 3000 – Electrical System

3000 – Electrical Circuits

3111 – Gauges

3120 – Controls ( electrical)

3 I 40 – Senders & Switches

3910 – Electrical Testing

Section 4000 – Power Train

4000 – Drive Train

4300 – Braking Systems

43 IO – Brakes

4600 – Planetaries/Final Drives – General

4610 – Planetaries/Final Drives

4800 – Tracks – General

4810 – Tracks

4820 – Idler

4910 – Speed Adjustment

Section 5000 – Cab

5500 – Air Conditioner/Heater Systems

5510 – Air Conditioning

Section 6000 – Frames and Panels

6510 – Gearbox/Planetary

6520 – Swing Bearing

6530 – Swing Brake

6800 – Undercarriage

6810 – Links

Section 9000 – Technical Information

9400 – Tool Lists & Drawings

9500 – Torque Values

9800 – General Machine Specifications

9810 – Fluids and Lubricants

9900 – Miscellaneous

Timberjack 608L Feller Buncher Service Repair Manual

To assist the operator in becoming familiar with the many features of this machine, and thereby become proficient in the operation and periodic maintenance procedures, this manual is provided with detailed operating and service instructions as well as safety information and equipment data.Throughout this manual, references are made to the front, rear, left, and right side of the machine. Consider the right side, left side, front, and rear, of the Forwarder from a seated position in the operator’s seat with the engine being at the front.

Where applicable throughout the text, “Safety Alert” symbols have been used to indicate important safety measures. Read carefully, understand, and follow these instructions to prevent hazardous situations that could lead to risk of personal injury.The instructions and procedures in this manual cover Forwarders with the most commonly used options; therefore pictorial presentation in some areas may vary slightly from the actual machine. This variation, however, does not have any impact on the accuracy of the written information. The information contained in this manual is current at the time of publication; however, continuing product improvement may result in changes to the machine which are not covered. Should information regarding such changes or further information on the machine be required, please contact your Timberjack dealer .
