Sumitomo SH130-5 Hydraulic Excavator Repair Service Manual
$45.00
Sumitomo Excavator SH130-5
Format: PDF
Manual Identification: WLST1305TS-01W, WLST1305-00T, WLSM1305-03W, WDL1205-0F_T00, WCL1305-0F_T00
English
- Sumitomo SH130-5 Hydraulic Excavator Repair Service Manual – 1671 Pages (Including Troubleshooting)
- Operators Manual – 230 Pages
- Parts Catalog – 492 Pages
Sumitomo Excavator SH130-5
Format: PDF
Manual Identification: WLST1305TS-01W, WLST1305-00T, WLSM1305-03W, WDL1205-0F_T00, WCL1305-0F_T00
English
- Sumitomo SH130-5 Hydraulic Excavator Repair Service Manual – 1671 Pages (Including Troubleshooting)
- Operators Manual – 230 Pages
- Parts Catalog – 492 Pages
Sumitomo SH130-5 Manual TABLE OF CONTENTS
- Engine Section
- Air Conditioner Section
- Maintenance Section
- Assembly and Disassembly Section
- Hydraulic Section
- Electrical Section
- Service Support
- Troubleshooting Manual
This Troubleshooting Manual explains troubleshooting of the engine electronic control fuel injection system (common
rail type) and main unit of the hydraulic excavator equipped with 4JJ1 type engine.
The Sumitomo Manual Preface
The purpose of this Sumitomo Excavator manual is to assist dealers and repair serviceman in efficient repair and maintenance of their machinery. Carrying out the procedures as detailed, together with the use of any special tools needed.
Using the Sumitomo SH130-5 Manual
To make information easier to find, there is an index at the beginning of each section listing the various parts in that section. At the beginning of each part there is a table of contents which should also be used as a guide to locate information.
To assist with locating information, each section of the manual is preceded by a contents page listing the repair operations, Each instruction within an operating has a sequence number. To complete the operation in the minimum time is possible follow the manual guideline and repair instructions.
When parts have to be replaced in either the SH130-5 Hydraulic Excavator , it is essential that only genuine Sumitomo parts should be used. Special attention should be paid to the following points concerning repairs and the fitting of replacement parts and accessories.
Indexing
For convenience the manual is divided into section and parts, each page bearing a section and part number. The sections are subdivided into numbered operation. This simplifies cross referencing and enable the subject to be found easily.
