Volvo Ec380d L, Ec380d NL Excavator Service Parts Catalog Manual
$51.00
Volvo Ec380d L, Ec380d NL Excavator Full Parts Catalog
Comprehensive technical guide designed for the maintenance, troubleshooting, and repair Manual. This manual provides detailed instructions, specifications, diagrams, and procedures to assist technicians and operators in servicing the machine effectively.
Volvo Ec380d L, Ec380d NL Excavator Service Parts Manual
Volvo Ec380d L Ec380dl Excavator Power Transmission
Volvo Ec380d L, Ec380d NL (ec380dl Ec380dnl) Excavator Service Parts Catalog Manual Instant Download Sn: 210001 And Up
Volvo Ec380d L Ec380dl Specifications
Service Repair Manual Covers:
Safety
0 General
1 Standard Parts, Service
2 Engine with Mounting and Equipment
3 Elect. System, Warning System, Information System, Instruments
4 Power Transmission
5 Frame and Crawler Unit
6 Machinery House, Cab, Exterior Trim Parts Anywhere
7 Hydraulic System, Digging, Handling, Grading Equipment, Misc Equipment
Hydraulic and Electric schematics
Volvo Ec380d L, Ec380d NL Excavator Service Parts Catalog Manual
Specification
Engine
Make Volvo
Model D13H
Gross Power 293 hp 218.5 kw
Net Power 283 hp 211 kw
Power Measured @ 1700 rpm
Displacement 781 cu in (ca. 13 l) 12.8 L
Torque Measured @ 1300 rpm
Max Torque 1165.3 lb (0.53 t) ft 1580 Nm
Number of Cylinders 6
Aspiration Turbocharged and Intercooler
Operational
Operating Weight, 84326.8 lb (ca. 38 t) 38250 kg
Fuel Capacity 163.8 gal (0.62 m³) 620 L
Cooling System Fluid Capacity 15.9 gal 60 L
Hydrauilc System Fluid Capacity 132.1 gal 500 L
Engine Oil Capacity 11.1 gal 42 L
Operating Voltage 24 V
Alternator Supplied Amperage 80 amps
Hydraulic System Relief Valve Pressure 5120 psi 35301.1 kPa
Hydraulic Pump Flow Capacity 158.5 gal/min 600 L/min
Swing Mechanism
Swing Speed 10.2 rpm
Swing Torque 96257 lb ft 130507 Nm
Undercarriage
Number of Shoes per Side 50
Shoe Size 27.6 in 700 mm
Number of Carrier Rollers per Side 2
Number of Track Rollers per Side 9
Ground Pressure 8.5 psi 58.8 kPa
Max Travel Speed 3.3 mph 5.3 km/h
Drawbar Pull 62181 lb 276.6 kN
Track Gauge 9 ft in 2740 mm
Buckets
Reference Bucket Capacity 3.2 yd3 2.4 m3
Maximum Bucket Capacity 3.6 yd3 2.8 m3
Boom/Stick Option (HEX) 1
Boom/Stick Option (HEX) 1 21’2″ (6450mm) boom / 8’6″ (2600mm) stick
Shipping Height of Unit 11.6 ft in 3530 mm
Shipping Length of Unit 37 ft in 11280 mm
Max Digging Depth 22.5 ft in 6850 mm
Max Reach Along Ground 33.9 ft in 10330 mm
Max Cutting Height 33.4 ft in 10170 mm
Max Loading Height 23.3 ft in 7090 mm
Max Vertical Wall Digging Depth 17.8 ft in 5430 mm
Boom/Stick Option (HEX) 2
Boom/Stick Option (HEX) 2 21’2″ (6450mm) Boom / 10’6″ (3200mm) Stick
Shipping Height of Unit 10.8 ft in 3280 mm
Shipping Length of Unit 35.9 ft in 10940 mm
Max Digging Depth 24.4 ft in 7450 mm
Max Reach Along Ground 35.6 ft in 10860 mm
Max Cutting Height 33.9 ft in 10340 mm
Max Loading Height 23.9 ft in 7280 mm
Max Vertical Wall Digging Depth 19.3 ft in 5870 mm
Boom/Stick Option (HEX) 3
Boom/Stick Option (HEX) 3 21’2″ (6450mm) Boom / 12’10” (3900mm) Stick
Shipping Height of Unit 11.4 ft in 3470 mm
Shipping Length of Unit 36.8 ft in 11220 mm
Max Digging Depth 26.7 ft in 8150 mm
Max Reach Along Ground 37.8 ft in 11520 mm
Max Cutting Height 34.8 ft in 10610 mm
Max Loading Height 24.8 ft in 7560 mm
Max Vertical Wall Digging Depth 21.3 ft in 6500 mm
Dimensions
Width to Outside of Tracks 11.6 ft in 3540 mm
Height to Top of Cab 10.6 ft in 3225 mm
Ground Clearance 1.7 ft in 530 mm
Counterweight Clearance 4 ft in 1210 mm
Tail Swing Radius 11.7 ft in 3560 mm
Length of Track on Ground 13.9 ft in 4240 mm
Volvo EC380D L EC380DL Excavator Service Repair Manual is written step by step in details, so you become very easy to repair by yourself. It can save your expenses.
File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader & WinZip
